Application :
For use of compression, tensile and more test. Compact
design and rigidly frame to ensure capability of any test.
Frame :
Maximum vertical clearence between platens : 340 mm
Maximum horizontal clearence : 250 mm
Upper and Lower platen diameter : 220 mm
Maximum travel of hydraulic piston : 100 mm
Mootorized Hydraulic Power Pack :
Electric consumption : 1000 watts, 1 phase
50-60 Hz, 220 V-AC. Double action, variable speed
Approximate reservoir oil capacity 6 liters ( 6000 ml)
Weight : Approximate Gross weight ( dry) : 500 kg
Accessories :
Distance block for concrete cube sample test,
15 cm and 20 sm as standard
Compression test adaptors
Pairs of grips for tensile test. 6' 10, 16 mm size
Dimension : Dimensions ( approx.) length x width x
height : 1500 mm x 1000 mm x 1500 mm
PP 24-1283-1 UNIVERSAL TESTING MACHINE ( UTM)
1000kN, Tensile Capacity
500kN, Compression Capacity
PP 24-1283-2 UNIVERSAL TESTING MACHINE ( UTM)
2000kN, Tensile Capacity
100kN, Compression Capacity
PP 24-1283-3 UNIVERSAL TESTING MACHINE ( UTM)
3000kN, Tensile Capacity
150kN, Compression Capacity
